Total-counter type Register ULTRA OVAL with BATCH CONTROLLER MODEL LW74E, LW76E

Format:LW74E, LW76E

Liquid

Gas

Steam

定量機能付ウルトラ計数部_容積流量計_01

定量機能付ウルトラ計数部_容積流量計_02

定量機能付ウルトラ計数部_容積流量計_01

定量機能付ウルトラ計数部_容積流量計_02

Positive displacement flowmeters "Ultra OVAL" and "Ultra UF-II" provided with batch controller. In combination with pneumatic auto ON/OFF valve, high performance field-type batch system can be configured easily.

Features
Product Specifications
Document

Features

• Fully pneumatic type (Batch controller is activated by the built-in battery.)
• Two models, valve one-step open/close type and valve 2-step open/close type, are available.
• As feed volume display and accumulated total display can be switched over, management of total volume is also available.

Major specifications

Type LW74E LW76E
制御方式 Pneumatic one-step open, one-step close Pneumatic two-step open and two-step close
(can be changed to one-step open)
Applicable
flowmeters
Ultra OVAL: 39 to 65 types (Nominal size: 10 to 350 mm)
Ultra UF-II: 80 to 88 type (Nominal size: 80 to 450 mm)
Flow range Ultra OVAL: 0.2 L/h to 1000 m3/h(17形式)*1
Ultra UF-II: 8 to 2800 m3/h(9 types)*2
Display Feed volume display: 6-digit LCD, accumulated total display: 8-digit LCD
Operation Front-panel keys (START, STOP, RESET)
Ambient
temperature range
–10 to +60°C
Power supply Battery-powered
Output None
Configuration Explosionproof or non-explosionproof, IP65

*1: 5 to 1000 mPa·s in viscosity

*2: 5 to 15 mPa·s in viscosity

Specification

*You need to fill out the questionnaire to download documents.

GBC201E-6

LW74E/LW76E
