Format：EL4801
The EL4801 calorie computer is a digital instrument designed with the latest electronic technology to fulfill the demand for faster calorimetry. The EL4801 calculates the calorific value of natural gas or city gas using the sonic velocity measured by an ultrasonic flowmeter. This instrument is also capable of simultaneous flow rate calculation by the flow velocity measured with the ultrasonic flowmeter.
Densitometers are commonly used for calorimetry of city gas and natural gas that does not include inert gas by using the correlation between molecular weight (density) of the gas and calorific value. This calorie computer, however, calculates calorific value by utilizing the correlation between molecular weight and sonic velocity as well as the correlation between process temperature/pressure and calorific value as computational logic.
This calorie computer was co-developed with Osaka Gas Co., Ltd.
Note: This computer is a dedicated computer for the ultrasonic flowmeter of OVAL product.
More
Liquid
Gas
Steam
Format：EL4321
In comparison with the previously offered instruments, substantial reduction in physical geometry, improved functions and ease of operation have been achieved. Included among the improvements in this newly developed instrument are simplified parameter changes and data logging with IC cards along with a large, easy-to-read LCD display.
This instrument receives density frequency signal from the density sensor and provides an analog output in proportion to the density of metered process fluid. In response to temperature and pressure signals, it also can provide an output corrected for reference conditions.
More
Liquid
Gas
Steam
Format：EL4311
In comparison with the previously offered instruments, substantial reduction in physical geometry, improved functions and ease of operation have been achieved. Included among the improvements in this newly developed instrument are simplified parameter changes and data logging with IC cards along with a large, easy-to-read LCD display.
This instrument receives mass flow signal and temperature/ density signals from the OVAL Coriolis flowmeter and, upon calucation, displays the total flow of solids content of pocess fluid that contains solids.
It also can display the corrected density for reference temperature and provide an analog output.
More
Liquid
Gas
Steam
Format：EL4301
In comparison with the previously offered instruments (OVAL EL4080 series), substantial reduction in physical geometry, improved functions and ease of operation have been achieved.
Included among the improvements in this newly developed instrument are simplified parameter changes and data logging with IC cards along with a large, easy-to-read LCD display.
This instrument receives tube oscillation signal and temperature signal from the OVAL Coriolis flowmeter and, upon calucation, displays the density of process fluid.
It also can display the corrected density for reference temperature and provide an analog output.
More
Liquid
Gas
Steam
Format：EL4401
Using the most advanced electronic technologies, this digital instrument has been developed specifically for crude oil and heavy oil blend ratio measurement applications where accuracy is the prime requirement.
In response to the flowrate, temperature, and blend ratio information arriving from the OVAL flowmeter, it converts the flowrate to the equivalent volume flowrate under standard conitions and totalizes the flow.
An analog output and instant flowrate (corrected for meter error and temperature) output are additional provisions.
More
Liquid
Gas
Steam
Format：EL4211
Using the most advanced electronic technologies, this digital instrument has been developed specifically to meet the most demanding fluid flow measurement applications where accuracy is the prime requirement.
In response to the flowrate and temperature information of fluid arriving from the sensing terminal, such as a flowmeter, it calculates fluid flow, reduced to the equivalent volume flow under standard conditions, and totalizes the flow.
In addition to meter error curve correction capabilities, a volumetric conversion factor as a quadratic function of temperature is introduced to implement density related weight conversion, giving you increased freedom to optimize compensated calculation.
An analog output and instant flowrate (corrected for meter error, temperature, and converted to mass) output are additional provisions.
With a model dedicated only to flow and pressure inputs, the instrument can also carry out calculations as a pressure compensator with fixed temperature value.
More
Liquid
Gas
Steam
Format：EL4501
Using the most advanced electronic technologies, this digital instrument has been developed specifically to meet the most demanding flow measurement applications in petroleum products receiving facilities where accuracy is the prime requirement.
In response to the liquid flowrate and temperature information arriving from the sensing terminal, such as a flowmeter, it totalizes the flow while implementing meter error and temperature corrections.
An analog output and instant flowrate (corrected for meter error and temperature) output are additional provisions.
More
Liquid
Gas
Steam
Format：EL4131
Using the most advanced electronic technologies, this digital instrument has been developed specifically to meet the most demanding liquid flow measurement applications where accuracy is the prime requirement.
In response to the liquid flowrate and temperature information arriving from the sensing terminal, such as a flowmeter, it totalizes the flow while implementing meter error and temperature corrections.
An analog output and instant flowrate (corrected meter error and temperature) output are additional provisions.
More
Liquid
Gas
Steam
Format：EL4201
Using the most advanced electronic technologies, this digital instrument has been developed specifically to meet the most demanding steam flow measurement applications where accuracy is the prime requirement.
In response to the gas flowrate, temperature, and pressure information arriving from the sensing terminal, such as a flowmeter, it calculates gas flow, reduced to the equivalent volume flow under standard conditions, and totalizes the flow.
In addition to meter error curve correction capabilities, a correction factor "X" as a quadratic function of temperature and pressure is introduced, giving you increased freedom to optimize compensated calculation.
An analog output and instant flowrate (corrected for meter error, temperature, and converted to mass) output are additional provisions. With a model dedicated only to flow and pressure inputs, the instrument can also carry out calculations as a pressure compensator with fixed temperature value.
More
Liquid
Gas
Steam
Format：EL4121
Using the most advanced electronic technologies, this digital instrument has been developed specifically to meet the most demanding gas flow measurement applications where accuracy is the prime requirement.
In response to the gas flowrate, temperature, and pressure information arriving from the sensing terminal, such as a flowmeter, it calculates gas flow, reduced to the equivalent volume flow under standard conditions, and totalizes the flow.
In addition to meter error curve correction capabilities, a correction factor "X" as a quadratic function of temperature and pressure is introduced, giving you increased freedom to optimize compensated calculation.
An analog output and instant flowrate (corrected for meter error and temperature) output are additional provisions.
With a model dedicated only to flow and pressure inputs, the instrument can also carry out calculations as a pressure compensator with fixed temperature value.
More
Liquid
Gas
Steam
Format：EL4111
Using the most advanced electronic technologies, this digital instrument has been developed specifically to meet the most demanding steam flow measurement applications where accuracy is the prime requirement.
In response to flowrate, temperature, and pressure information arriving from the sensing terminal, such as a Vortex flowmeter, it calculates superheated steam flow, transforms it to mass and calorie, and totalizes the flow.
It also provides a totalizer pulse output and an instantaneous flowrate analog output(mass equivalent).
More
Liquid
Gas
Steam
Format：EL4101
Using the most advanced electronic technologies, this digital instrument has been developed specifically to meet the most demanding steam flow measurement applications where accuracy is the prime
requirement.
In response to flowrate and temperature information arriving from the sensing terminal, such as a Vortex flowmeter, it calculates “dryness factor of 1” saturated steam flow, transforms it to mass and calorie, and totalizes the flow.
It also provides a totalizer pulse output and an instantaneous flowrate analog output (mass equivalent).
More
Liquid
Gas
Steam
Format：EL4061
Specifically intended for steam service, this instrument accepts signals from a steam service Delta Flowmeter.
It contains a microprocessor to perform steam pressure setting relative to the service pressure, bore setting and individual meter calibration, and indicates the total flow in terms of weight for accurate and precise flow measurements.
